Dual-Output Controllers
In each Quick-Kit, there are some CP2-4-5 dual-output controllers. Each dual-output controller can operate two separate electrical loads independently.
1.5A Output (Red Wire)
One of the CP2-4-5 outputs has a red wire for 1.5A on/off or dimming functions. Connect this output to lights (not motors) in habitable areas (e.g. bedroom, kitchen).
2.0A Output (Yellow Wire)
The second output has a yellow wire that can do 2.0A on/off switching. Connect this output to motors or lights that do not need dimming (e.g. pantry light, fan motor).
Default Locations for Dual-Output Controllers
Every house has locations where dual-output controllers can be used without special wiring.
| Red Wire (1.5A) | Yellow Wire (2.0A) | Rooms |
| Vanity or ceiling light | Exhaust fan | Bathrooms, laundry and utility rooms |
| Ceiling fan light | Ceiling fan motor | Bedrooms, living room, great room |
| Entry / foyer light | Exterior porch light | Porch and entry |
| Room light | Exterior patio light | Dining room, great room w/ exit to patio |
Deploy dual-output controllers to places where it's convenience to switch two separate loads from one controller module.
